7.5kw / 10hp 0.98 m³/min Simple Structure Belt Air Compressor
8.5mpa 900*660*960
Adopt design line, with large displacement;High volume ratio, no
friction loss and high mechanical efficiency;Simple and compact
structure, mature and reliable products and reasonable cost;The
main engine has few parts, no wearing parts and low maintenance
cost;It is convenient and quick to change the working pressure
demand by simply replacing the pulley.
Technical parameters:
Model
Specification | |
|
| (M³/Min/Mpa) | 0.98m³/min 8.5mpa |
| Power Kw/ HP | 7.5KW/10HP |
| Ambient Temperature ℃ | 8℃-40℃ |
| Cooling Mode | Air Cooling/water cooling |
| Discharge Temp | ≤Ambient +15℃ |
| Lub Oil Capacity (Liter) | 10L |
| Noise Level Db(A) | 62 |
| Driven Mode | Belt Drive |
| Power (V/Ph/Hz) | 380V/50Hz |
| Starting Mode | Direct driven |
| Dimension (mm) | 900*660*960 |
| Net Weight (kg) | 200 |
| Out let Diameter (inch) | RP3/4 |
1 High precision screw head. Repeated optimization, optimizing the
high efficiency screw head, providing users with large displacement
and prolonging service life.
2 Efficient asynchronous motor.The whole machine adopts
high-efficiency asynchronous motor with small vibration.Adopt air
cooling ,Greatly reduce motor current and stably control motor
temperature rise.
3 Specially designed intake valve set:The specially designed
large-diameter intake valve set has lower pressure loss and longer
service life, providing a service experience close to zero failure.
4 High-quality air filter:stable and high-quality air filter, using
imported filter materials, can effectively filter impurities in the
air, greatly prolong the service life of screw machine, and reduce
the use cost of users at the same time
Advantages of Kapa brand
Advantages:
1. High quality control(ISO 9001-2000/ISO14001/ASME/Energy saving
certificate)
2. Fast Delivery( 10-15 days for large orders)
3. Good service for pre-sale,after-sale( strong technical support
and professional after-sales team)
4. Small order acceptable( Ordering quantity according to your
actual needs)
why choose us
Longer service life of the master machine
The rotor uses asymmetrical line running at a low speed with the
support of the ball bearings and roller bearings as a result. The
damage and the cost are lowered and the service life is extended.
Some force is counteracted by the axial force generated by the
bevel gear. So the load on the bearings of the master machine is
lowered.
Permanent alignment of the electromotor and the master machine
Different from the strap compressor, the SRC series compressor can
integrate the electromotor with flange, shaft coupling box-gear
box. and the master machine into one in such way the master machine
and the electrometer are aligned forever in the transpiration. The
SRC series compressors equipped with effective and fully sealed
air-cooling electromotor.
FAQ
Q1: Are you factory or trade company?
A1: We are factory. And we have ourselves trading company.
Q2: What the exactly address of your factory?
A2: Our company is located in Zone B, Lianhua County Industrial
Park, Pingxiang City, Jiangxi Province of China
Q3: Warranty terms of your machine?
A3: One year warranty for the machine and technical support
according to your needs.
Q4: Will you provide some spare parts of the machines?
A4: Yes, of course.
Q5: What about the voltage of products? Can they be customized?
A5: Yes, of course. The voltage can be customized according to your
equirement.
Q6: Which payment term can you accept?
A6: 30% T/T in advanced, 70% T/T against the B/L copy.
Q7: How long will you take to arrange production?
A7: 380V 50HZ we can delivery the goods within 10 -15 days. Other
electricity or other color we will delivery within 25-30 days.
Q8: Can you accept OEM orders?
A8: Yes, with professional design team, OEM orders are highly
welcome.
Q9: Which trade term can you accept?
A9: Available trade terms: FOB, CIF, CFR, EXW, CPT, etc.
