160kw Two Stage Screw Air Compressor 31.78 m³ / min 2980*1880*2160
Description
Save energy 10-15% compare with one stage;
The compression efficiency is 12-18% higher than one stage;
Vibration is 15-30% lower than one stage.
| Air intake status | ≤Ambient temperature intake pressure 1.013bar(A) | Voltage(V)
Frequency(Hz) | 380V50Hz |
| Start-ups | Y-△ | Noise dB(A) | 72±5dB |
| Oil Content | 1~3ppm | Outlet Air Temperature | ambient temperature+8℃ |
- Two stage energy saving screw air compressor air end:
Ten years screw compressor air end experience
Produces 100,000pcs air end yearly
Developed two stage compressor energy saving air end
2. Energy saving special motor:
4-stage motor drive
With Low rotating speed, low noise
Small starting current
Large moment output
More smoothly running
3. Smart control system:
Adopt high efficiency double control screen design
(Touch screen+mechanical button)
Four control mode:
Automatic control
Manual control
Multi-machine combination
Remote control
⊙ Schematics
| 1. Air Filter | 9. Oil Temperature Control Valve |
| 2. Air-in Easing Value | 10. Oil Filter |
| 3. Principal Screw Machine | 11. One-way Shut-off Valve |
| 4. Oil Air Separator | 12. Pressure Gage |
| 5. Oil Air Separating Filter Core | 13. Safety Valve |
| 6. Minimum Pressure Valve | 14. Vent Valve |
| 7. Radiator with Aluminum Alloy Fans | 15. Compressed Air Dry Separator |
| 8. Return Check Valve | 16. Motor |
Specification
| Model Specification | KP160-0.8II |
|
| Displacement/Pressure (M³/Min/Mpa) | 31.78/0.8 |
| Power Kw/ HP | 160KW/215HP |
| Ambient Temperature ℃ | 2℃-45℃ |
| Cooling Mode | Air-Cooling |
| Discharge Temp | ≤Ambint+15℃ |
| Lub Oil Capacity Liter | 42.3L |
| Noise Level Db(A) | 61.2 |
| Driven Mode | Direct Drive |
| Power V/Ph/Hz | 380V/50Hz |
| Starting Mode | power frequency |
| Dimension mm | 2980*1880*2160 |
| Net Weight kg | 3850 |
| Out let Diameter inch | DN80 |
Advantages:
1. High quality control(ISO 9001-2000/ISO14001/ASME/Energy saving
certificate)
2. Fast Delivery( 10-15 days for large orders)
3. Good service for pre-sale,after-sale( strong technical support
and professional after-sales team)
4. Small order acceptable( Ordering quantity according to your
actual needs)
why choose us
Longer service life of the master machine
The rotor uses asymmetrical line running at a low speed with the
support of the ball bearings and roller bearings as a result. The
damage and the cost are lowered and the service life is extended.
Some force is counteracted by the axial force generated by the
bevel gear. So the load on the bearings of the master machine is
lowered.
Permanent alignment of the electromotor and the master machine
Different from the strap compressor, the SRC series compressor can
integrate the electromotor with flange, shaft coupling box-gear
box. and the master machine into one in such way the master machine
and the electrometer are aligned forever in the transpiration. The
SRC series compressors equipped with effective and fully sealed
air-cooling electromotor.
FAQ
Q1: Are you factory or trade company?
A1: We are factory. And we have ourselves trading company.
Q2: What the exactly address of your factory?
A2: Our company is located in Zone B, Lianhua County Industrial
Park, Pingxiang City, Jiangxi Province of China
Q3: Warranty terms of your machine?
A3: One year warranty for the machine and technical support
according to your needs.
Q4: Will you provide some spare parts of the machines?
A4: Yes, of course.
Q5: What about the voltage of products? Can they be customized?
A5: Yes, of course. The voltage can be customized according to your
equirement.
Q6: Which payment term can you accept?
A6: 30% T/T in advanced, 70% T/T against the B/L copy.
Q7: How long will you take to arrange production?
A7: 380V 50HZ we can delivery the goods within 10 -15 days. Other
electricity or other color we will delivery within 25-30 days.
